Drive mode

Step motor

Axis

5

Application programming interface

Teach Box

Temperature range

180-450 *C

Working Range

X500*Y400*Z100*U360°

Maximum Speed

X,Y500 mm/s, Z 250 mm/s

Repeatability Accuracy

 + - 0.02mm

Maximum Load of Table

10 kg

 heating

200W/ 300W

 Voltage

AC220V/50HZ

Solder Wire Diameter

0.6-1.5

Number of Program

9999

Air Source

Clean 0.4-0.6 kpa

Weight

65 kg

Dimensions

L680*W750*H800mm

Single Point Welding Time

0.2s-100s
